ZEON 10
WARN
WARN ZEON WINCHES
Engineered from the ground up, the ZEON winch range sets a new standard in Warn’s premium winch range. Smoother, quieter, stronger and better sealed with an IP68 rating makes this range ready for serious action.
A convertible control pack provides plenty of flexibility by allowing the pack to be removed and mounted separately from the winch. Not only does this allow the winch to be mounted in tight spaces, it also provides the option of a more low profile look.
The ZEON winch range also includes a limited lifetime warranty.
ZEON 10
It might have a stylish new design but do not be fooled, the ZEON 10 winch is built to last. With features such as a heat dissipating brake, smooth planetary gear train, integrated look, new motor, fast line speed and IP68 rating, the ZEON range is full of features that are sure to satisfy the serious 4wder.
SPECS:
- Maximum Load – (Single Line) | 4536kgs (10,000lbs)
- Motor - 12V DC, series wound
- Control - Remote switch, 3.7m lead
- Gear Train - 3 stage planetary
- Gear Ratio - 216:1
- Clutch – (Freespooling) - Rotating ring gear
- Cable - 9.52mm x 24.38m
- Brake - Automatic mechanical cone
- Dimensions With Control Pack - L 61.59cm x W 18.16cm x H 26.71cm
- Dimensions Without Control Pack - L 61.59cm x W 18.16cm x H 19.9cm
- Drum Diameter/Length - 8cm/22.9cm
- Weight- 44kg
